chm-t36va is a vision-based desktop pick and place machine
which need connect external pc with windows 7 system.
it is very reliable with low-cost economic model,
this small platform machine comes with advance vision system,
closed-loop control, 29pcs material stacks. high precision and easy operation software.
it compatible all different kinds of components 0402-5050,sop, qfn, tqfp...
very suitable for for prototype builders, hobbyists, developers, and development groups
and small batches production,
you just need to prepare a computer which has usb port
parameters
model | chm-t36va |
pcb area | 10mm*10mm - 355mm*355mm |
x y z axis travel | 400*460*15mm |
placement heads | 2pcs |
feeders | 8mm=22pcs, 12mm=4pcs, 16mm=2pcs, 24mm=1pcs |
vision system | dual cameras(up & down cameras) |
drive | closed-loop control stepper servo drive system, make sure never lose step |
z axis self-return detection | yes, prevent nozzles breaking |
pull pin self-return | yes |
leakage of material detection method | vacuum detection, vision detection |
mounting speed | 4000cph (vision off); 2500cph (vision on) |
mounting precision | ±0.025mm |
components | 0402-5050,sop,qfn etc(tape width: 8mm,12mm,16mm,24mm) |
machine dimension | l 960mm * w 705mm * h 335mm |
vacuum pump | -92kpa (2pcs,build-in, mute type) |
external air source | no need (machine build-in mute vacuum pump 2pcs) |
external pc | yes (software compatible with windows7) |
voltage | 220v /110v |
net weight | 65kg |
gross weight | 76kg |
our service
this smt machine will be tested well before ship out.
tools and manuals are complete included in the package.
each machine 100% test well before ship out.
support as well as a long term factory price supply.
we provide online q/a and troubleshooting support and technical advice service.
provide one to one after-sale service.
